Orion 911600 EPOXY SEMI-MICRO COMB PH ELECTRO BNC 1M

Specs & Details
Segment	WAI Lab
Unit	Water Analysis
Family	Lab Electrodes
Class	Consumables
Major Code	pH/ORP Sensors
Minor Code	LPH2- pH/ORP Sensors
Connector Types	BNC
Description	Permanently gelled Ag/AgCl electrolyte
Diameter English Body	0.25 in.
Diameter English Cap	0.18 in.
Diameter Metric Body	6 mm
Diameter Metric Cap	10 mm
For Use With Equipment	Orion pH Meter
Junction	Wick
Length English	5.93 in.
Length Metric	15 cm
Length Metric Cable	1 m
Material	Epoxy
PH Range	0 to 12
Temperature English Operating	32°F to 176°F
Temperature Metric Operating	0°C to 80°C
Type	Combination Ag/AgCl pH Electrode, non-refillable, semi-micro
Unit Size	Each

Conduct routine pH measurements with the Thermo Scientific™ Orion™ Economy Series pH Combination Electrode. This routine wick junction, gel-filled electrode has an unbreakable epoxy body that extends beyond the pH sensing glass bulb, making it ideal for rugged conditions. It provides durability for both lab or field use with a low-maintenance design that requires no fill solution.

Permanently gelled Ag/AgCl electrolyte
9106BNWP has 0 to 14 pH range; all others have , 0 to 12 pH range
0° to 80°C (32° to 176°F) temperature range
General purpose and flat surface models: 4.31 in. long (11cm) × 0.43 in. diameter (12mm) body, 0.62 in. diameter (16mm) cap
Semimicro Model: 5.93 in. long (15cm) × 0.25 in. diameter (6mm) body, 0.18 in. diameter (10mm) cap

91-06 Model:

Waterproof BNC connector

General Purpose, Flask, Semimicro and Flat Surface Models:

BNC connector

Warranty: 3 months from date of purchase by Buyer or 6 months from date of shipment from Seller, whichever is earlier.
